Dual Energy Airport Luggage Scanners , 56 x 36cm Small Security Baggage Scanner

Dual Energy Airport Luggage Scanners , 56 x 36cm Small Security Baggage Scanner

General Specifications:

Tunnel Size.........................................560 (W) ×360 (H) mm

Wire Resolution..................................40AWG

Steel Penetration................................40mm

Conveyor Max Load............................150 kg

Leakage radiation.............................. <0.06µGy/h

Single inspection dosage.................... <1.01μGy

Conveyor Speed................................. 0.22m/s

Film Safety.......................................... For ISO 1600

X-RAY Sensor.................................. L-shaped array detector, 24bit

X-RAY GENERATOR:

Tube Current.......................................0.4-1.25mA(adjustable)

Anode Voltage.....................................80-160KV(adjustable)

Orientation.......................................... Upward

Angle...................................................80°

Generator cooling/working periods..... Sealed oil bath with forced air/100％

OPERATING ENVIRONMENT

System Power..................................... 220 VAC (±10%) 50±3HZ

Power wastage................................... 1.0 KW (Max)

Noise...................................................55DB

Storage Temperature......................... -20oC to 60oC

Operating Temperature...................... 0oC to 45oC

Relative Humidity.................................20 to 95% non-condensing

Image Performance System:

• Display: High-resolution 19 inch color LCD display
• Color quality: 24-Bit real colors based on materials
• Edge enhancement: Object contour edge is more distinct
• Super image enhancement: Image detail is more distinct
• High penetration display: Increase the contrast of bright area in image to make the area that is easy to penetrate appear more clearly
• Low penetration display: Increase the contrast of dark area in image to make the area that is difficult to penetrate appear more clearly.
• Magnifier: Partial magnifying function
• Brightening/dimming: Increase/Decrease brightness of image
• Image recurrence: Display the previous twenty images and process any one of them
• Image restoration: Restore image to initial status
• Image storage: Real-time store any image and process it in operation status

Multi-energy: High/low energy: Switch from high energy to low energy

Color material identification: Organic objects in orange, inorganic objects in blue, mixture in green

Assist to detect drug and explosive powder

Special features:

• Network interface: Capable of connecting to LAN, and support multi-terminal check for baggage at same time,
• Safety ray: Ray is transmitted under automatic control, avoiding the error,
• One-key shutdown control: Just rotate the key to shut down the machine; it is safety, easy and convenient
• Eagle eye: Capable of expediently observing the magnifying area
• Self-diagnosis function: Give message automatically if malfunction for prompt maintenance

Applications:

• Commercial buildings
• Factories(to find needle in clothing, shoes, bags)
• Courthouses
• Embassies
• Government buildings
• Military installations
• Prisons
• Hotels
• Schools
• Convention centers
• Security checkpoints

Competitive Advantage:

• Innovative & Economical

• World Class Reliability
• Long-Term Flexibility
• Ease of Use Increases Efficiencies
• Ease of Maintenance

• Competitive Price and Professional Service
