Sealed Oil Cooling Security Baggage Scanner Big Size For Metro Station

Name: Sealed Oil Cooling Security Baggage Scanner Big Size For Metro Station
Brand: Uniqscan
Price: 6000 USD

Brand Name : Uniqscan

Model Number : SF100100

Certification : CE ISO

Place of Origin : China

MOQ : 1 UNIT

Price : 6000- 18000 usd/unit

Payment Terms : T/T

Supply Ability : 50000pcs per month

Delivery Time : in one week

Packaging Details : Wooden box

Product Name : Big size x ray security scanner

Power Requirement : 220V AC (±10%) 50±3Hz

Tunnel size : 1000*1000mm

Noise level : <58dB

Conveyor Speed : 0.22m/s

Conveyor Max Load : 1000 kg

Wire Resolution : 38AWG

Spatial Resolution : 1.0mm Horizontal and Vertical

Steel penetration : 40mm

Generator : Dual energy

Contact Now

Uniqscan Conveyor big size x-ray baggage scanner luggage scanner metro jail

Technical Specifications

Specifications:
Model Number	SF100100
Passageway Size	1000(W)*1000(H) mm
Penetration	mm Steel plate
Belt Max Load:	200Kg
Dose per inspection:	<2Gy/h
Resolving power	38AWG
Film Safety	Guarantee ISO1600 Film
X-Ray leakage	<0.2µGy/h
Ray beam spread angle	80 degree
Tube Voltage	150-200KV
Tube power	1-1.5mA
Cooling/work Cycle	Sealed Oil Cooling /100%
Multi-energy/Distinguish objects	organic objects in orange,inorganic objects in blue,mixture in green
Belt speed	0.22m/s (adjustable)
Display	HD 19’’LCD display
High-energy/low energe	Two kinds of energy switch display
Image restoration	Image display restore the origional status
Certificates	CE /OHSAS18001/ISO19001/ISO9001

Sealed Oil Cooling Security Baggage Scanner Big Size For Metro Station

Special features:

Japan HAMMATSU detecting sensor, INTERRoll electronic Roller

Network interface: Capable of connecting to LAN, and support multi-terminal check for baggage at same time

Safety ray: Ray is transmitted under automatic control, avoiding the error

One-key shutdown control: Just rotate the key to shut down the machine; it is safety, easy and convenient

Eagle eye: Capable of expediently observing the magnifying area

Self-diagnosis function: Give message automatically if malfunction for prompt maintenance

Environment Specifications:

Operating temperature/humidity: 0℃ ~ 45℃/20% ~ 95% (Non-condensing)

Storage temperature/humidity: -20℃ ~ 60℃/20% ~ 95% (Non-condensing)
