Small Size X - Ray Security Baggage Scanner For Luggage , 500*300 Opening Size

Product Categories
SHENZHEN UNISEC TECHNOLOGY CO.,LTD
Contact Now

Small Size X - Ray Security Baggage Scanner For Luggage , 500*300 Opening Size

Brand Name : Uniqscan

Model Number : SF5030A

Certification : CE ISO

Place of Origin : China

MOQ : 1 UNIT

Price : Negotiation

Payment Terms : T/T, Western Union, L/C

Delivery Time : in one week

Packaging Details : Wooden box

Product Name : baggage scanner

Conveyor Speed : 0.22m/s

Conveyor Max Load : 100 kg

Single inspection dosage : < 1.32μGy

Wire Resolution : 40AWG

Tunnel Size : 500 (W) ×300 (H) mm

Penetration : 10mm Steel

Orientation : Upward

Contact Now

Small Size X - Ray Security Baggage Scanner For Luggage , 500*300 Opening Size

Competitive Advantage:
Integrated, cost Effective, Turn-Key Security
Fit for small Baggage and Parcel Security Inspection.
Increased detection capability
Friendly interface for ease-of-use
Reliable performance and uncompromising value

Specifications:

Tunnel Size: 500(W)*300(H)mm
Conveyor Speed: 0.22m/s
Conveyor Max Load: 100kgs
Single inspection dosage: < 1.0μGy
Wire Resolution: 40AWG
Penetration: 10mm Steel
Film Safety: Guarantee ISO1600 Film
X-ray Leakage: <0.1 μGy/h (at a distance of 5cm From external housing)
Generate direct: Upward
Generate angle: 60 degree
Anode Voltage: 80Kv
Anode power: 0.4 to 0.7mA
Cooling / Duty Cycle: Oil Cooling /100%
X-ray Sensor: L-Shaped Photodiode Array (mono-energetic), 24bit Deep
Monitor: High Resolution Color, LCD Accord, 19 inch
Image Processing: Edge enhancement, image strengthening, image lightening,
reducing darkening, image returning, image retrieval.
Image Grey Level: 4096
Image Max Resolution: 1024 * 1280 pixel
Image Processing: 24bit for processing real time
Image storage: Storage 100000 pictures in real time
Zones & Zoom: 64 Image regions, 2, 4, 8, 16,32,64 Times Enlarge,
Whole screen continuous observation
Operation temperature/Humidity: 0ºC-45ºC/20%-95%(non-condensing)
Storage Temperature/Humidity: -20ºC-60ºC/20%-95%(non-condensing)
Operation Power: 220VAC(±10%)50±3Hz
Power Consumption: 1.0 KW (max), 0.3KW(working)
Noise: <65db


Application:

End user Recommend X Ray Baggage Scanner model NO.
Airports, Transport terminals SF6040; SF6550; SF10080; SF100100
Factories (to find needle in clothing, shoes, bags), SF5030; SF5636; SF6040; SF6550
Courthouses, Embassies, Buildings SF5030; SF5636; SF6040; SF6550
Military installations SF5030; SF6040; SF6550; SF8065; SF100100
Prisons, Hotels, Schools, Convention centers SF5030; SF5636; SF6040; SF6550; SF10080
Security checkpoints,Special events location SF5030; SF6040; SF6550; SF8065; SF10080

Small Size X - Ray Security Baggage Scanner For Luggage , 500*300 Opening Size
